What We Can Build for You
Complete technical specifications for our PCB manufacturing capabilities. All manufacturing processes (shearing, drilling, plating, etching, HASL & testing) are conducted 100% in-house (except film plotting).
Manufacturing Specifications
Standard capabilities available for every order. Contact us for advanced or custom requirements.
| Parameter | Standard Capability | Notes |
|---|---|---|
| PCB Layers | 1 Layer (Single-Side), 2 Layer (Double-Side PTH) | Unclad (no copper) |
| Base Material | FR-4 | FR-4 High-Tg on request |
| Board Thickness | 0.8 / 1.0 / 1.2 / 1.6 / 2.0 / 2.4 mm | Custom on request |
| Max Board Size | 500 × 600 mm | Panelization available |
| Min Board Size | 10 × 10 mm | |
| Copper Weight (Outer) | 1 oz (35 µm) | 2 oz on request |
| Surface Finish | HASL | |
| Solder Mask Colors | Green, White, Black, Blue, Red, Yellow | 6 colors standard |
| Silkscreen | White (standard) | Black, Yellow on request |
| Min Drill Hole | 0.3 mm | 0.2 mm (laser drill) |
| Drill Accuracy | ± 0.05 mm | |
| Min Trace Width | 0.15 mm (6 mil) | |
| Min Spacing | 0.15 mm (6 mil) | |
| Board Testing | 100% — FPT (Flying Probe Testing) | |
| IPC Standard | IPC Class 2 | IPC Class 3 on request |
| RoHS Compliance | Yes |
State-of-the-Art Machinery
Our Pune facility is equipped with precision machinery for every stage of PCB manufacturing.
PLURITEC 2-Spindle Drilling & Routing Machine
PLURITEC 2-Spindle Drilling & Routing Machine
High-precision multi-station CNC drilling and routing for accurate hole placement and board profiling.
Chinese ZBX V8 Flying Probe Test Machine (FPT)
Chinese ZBX V8 Flying Probe Test Machine (FPT)
High-speed Chinese ZBX V8 automated flying probe test machine for 100% electrical continuity and isolation testing of every PCB.
Techniet Engineering Chemical Etching Line
Techniet Engineering Chemical Etching Line
Brand-new chemical etching line from Techniet Engineering for precision track definition and copper removal.
Techniet Engineering Brushing & Surface Prep Machine
Techniet Engineering Brushing & Surface Prep Machine
Brand-new mechanical brushing and surface preparation line from Techniet Engineering for optimal copper adhesion.
Techniet Engineering PTH & Pattern Plating Tanks
Techniet Engineering PTH & Pattern Plating Tanks
Brand-new Plated Through-Hole (PTH) and pattern copper plating tanks from Techniet Engineering.
Techniet Engineering HASL Machine
Techniet Engineering HASL Machine
Brand-new Hot Air Solder Leveling (HASL) chemical surface finishing line from Techniet Engineering.
Dry Film Laminator
Dry Film Laminator
Precision dry film lamination for consistent photoresist application across board surfaces.
Screen Exposure Machine
Screen Exposure Machine
UV exposure system for precise pattern transfer from artwork to PCB during the imaging process.
Shearing Machine
Shearing Machine
Industrial shearing machine for precise laminate cutting to required board dimensions.
Our 6-Stage Quality System
Every PCB goes through a rigorous 6-stage quality process from raw material to dispatch.
Have a Specific Requirement?
If your design needs are outside standard parameters, contact our engineering team. We can often accommodate custom requirements.
